Product Details
Place of Origin: dongguan,China
Brand Name: HOTHMI
Model Number: TFT-H185E01FHIYZ8C30
Payment & Shipping Terms
Minimum Order Quantity: 2
Delivery Time: 25 days
Payment Terms: L/C, D/A, T/T, D/P, Western Union, MoneyGram
Supply Ability: 99999
Display Content: |
1920x1080 Dot Matrix |
Dimensions (mm): |
450.0x272.0x5.0 |
Field Of View Window Size: |
IPS Full Viewing Angle |
Backlight Brightness: |
850cd/m2 |
Driver Chip: |
ILI2510 |
Interface: |
LVDS |
Operating Temperature:: |
-20~70℃ |
Display Content: |
1920x1080 Dot Matrix |
Dimensions (mm): |
450.0x272.0x5.0 |
Field Of View Window Size: |
IPS Full Viewing Angle |
Backlight Brightness: |
850cd/m2 |
Driver Chip: |
ILI2510 |
Interface: |
LVDS |
Operating Temperature:: |
-20~70℃ |
This 18.5-inch 1920x1080TFT capacitive touch display enhances your visual and interactive experience with precise specifications and outstanding performance.
This product adopts a normally black TFT panel, with a 72% NTSC color gamut and 850 cd/m ² brightness, which can present clear and sharp high contrast images even in bright environments. Its anti glare (AG) surface treatment can minimize reflection and provide a comfortable viewing experience. This display screen can operate reliably within a temperature range of -20 ° C to+70 ° C, and supports power inputs of 5.0V ± 0.5V (VCI) and 12.0V ± 0.5V (VLED). It also integrates capacitive touch functionality through a USB interface for seamless interaction. Chemical strengthened glass, 3M VHB adhesive installation, and industrial grade connectors (CN1_UJU IS100-L30O-C23/CN2-CIO114M1HR0-NH) ensure its durability, while the LVDS 48 bit interface supports high-speed data transmission.
This 18.5 TFT touch screen is a capacitive touch mode controlled by the ILI2510 chip, with multi touch and sensitive touch experience, providing users with a unique and smooth experience. For touch screen panels, we also offer customized services where users can customize printed fonts, graphics, colors, or customize panels of different sizes with rounded corners according to their actual needs. This TFT and the main control board transmit data through FPC, providing a very convenient way for assembling and disassembling modules. We can also customize wiring according to user needs.
This 18.5-inch 1920x1080TFT capacitive touch display is perfect for self-service terminals, medical equipment, and control systems. It combines rigorous technology with user centered excellence - every parameter is carefully designed to enhance your hardware experience.
| ITEM | PARAMETER DESCRIPTION | UNIT |
| TFT series | TFT-H185E01FHIYZ8C30 | |
| Diagonal size | 18.5” | Inch |
| Resolution | 1920x1080 | Dot |
| Dimensions | 450.0x272.0x5.0 | mm |
| Active area (AA) | 408.96x230.04 | mm |
| LCD type | 18.5” TFT Module | mm |
| Display viewing angle | Full View | |
| Aspect ratio | 2:1 | |
| Backlight type | LED white | |
| TFT driver IC | - | |
| Brightness | 850cd/m2 | cd/m2 |
| Operating temperature | -20~70℃ | ℃ |
| Storage temperature | -25~80℃ | ℃ |
