Product Details
Place of Origin: Dongguan, China
Brand Name: HOTHMI
Model Number: HTM2002C
Payment & Shipping Terms
Minimum Order Quantity: 2
Delivery Time: 25 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 99999
Show Contents: |
20X2 Character |
Outline Size(mm): |
180.0x40.0x11.0 |
Display Size(mm): |
142.8x20.64 |
Point Spacing(mm): |
1.22x1.22 |
Visual Angle: |
6H |
Backlight Type Or Brightness: |
Yellow-green |
Show Contents: |
20X2 Character |
Outline Size(mm): |
180.0x40.0x11.0 |
Display Size(mm): |
142.8x20.64 |
Point Spacing(mm): |
1.22x1.22 |
Visual Angle: |
6H |
Backlight Type Or Brightness: |
Yellow-green |
HTM2002C | 20x2 Character LCD | STN+ Yellow/Green Display with Yellow/Green Backlight
1. Character LCD Display 20x2
2. 5x8 dots includes cursor
3. +5V power supply (Also available for +3V)
4. Negative voltage optional for +3V power supply
5. 2/20 duty cycle
6. LED can be driven by PIN1, PIN2, PIN15, PIN16 or A and K
7. Interface: 6800 (ST7066U IC or Equivalent)
This model No.HTM2002C Character LCD Display is made of 20x2 Character matrix.
This display 20x2 character model is built-in ST7066U IC or equivalent which default
interface is 6800 4/8-bit parallel. It’s also available in MCU/8bit interface by using
ST7066U controller IC. The LCD panels are available in STN, FSTN, FFSTN types
and also with polarizer positive mode and negative mode options. There are different
LED backlights are available in various colors including yellow/green, white, red, blue,
green, amber, and RGB LEDs as well as no backlight option.
